Multi size all in one information LCD touch inquiry interactive horizontal display kiosk machine screen (A)
horizonal inquiry machine 16
$700
Feature: inquiry interactive machine;LCD touch inquiry machine;LCD touch inquiry screen;horizontal display kiosk
Size: 32'';50'';55'';65'';43'';49''
Operation System: Android;Windows
Screen: Touchscreen
Installation: Horizontal;Portable
Type: Advertising Machine;Digital Signage Display
Product Details
Product Details
Application guide for public service scene of cold-rolled steel plate body of horizontal inquiry machine display screen
Wide temperature adaptation of horizontal inquiry machine display screen at -20℃~60℃;
A, horizontal inquiry machine display screen width and temperature adaptation core features: coping with extreme environment of public service scene.
Temperature adaptation range and technical support: the display screen of horizontal inquiry machine has wide temperature working ability of-20℃~60℃, which breaks through the environmental limitation of conventional electronic equipment (mostly 0℃~40℃).
Its core lies in the customized temperature control scheme-in the low-temperature environment, the screen backlight module has a built-in heater, and the core temperature of the screen can be raised above 5℃ within 3 minutes after the display screen of the horizontal inquiry machine is powered on, so as to avoid the afterimage and response delay of the LCD screen due to low temperature.
In high temperature environment, the fuselage is equipped with dual industrial control and dustproof axial fans, which cooperate with the honeycomb cooling holes of the display screen body of the cold-rolled steel plate horizontal inquiry machine to form a convection cooling channel of "bottom air inlet+top air outlet", and control the temperature of the core components (CPU and power module) inside the display screen of the horizontal inquiry machine within 55℃ to prevent the system from being stuck and automatically shut down due to high temperature.
Humidity and stability supplement of horizontal inquiry machine display screen: In addition to temperature adaptation, horizontal inquiry machine display screen equipment supports 10-90% RH dew-free working humidity.
In the rainy season in the south and dry winter in the north, the moisture-proof coating inside the fuselage can isolate moisture and avoid short circuit of the circuit board.
At the same time, the wide temperature capacitance/infrared touch module has been tested by high and low temperature cycle (repeatedly switched for 500 times from-20℃ to 60℃), and the touch sensitivity and accuracy of the display screen of the horizontal inquiry machine are not attenuated, ensuring normal interaction in extreme environment.
B, cold-rolled steel plate horizontal inquiry machine display screen body: durability guarantee of public service scene
Material characteristics and structural advantages: the fuselage is made of cold-rolled all-steel plate, with a thickness of 1.2mm, and the surface is treated by electrostatic spraying process, with hardness of HB200, which has the characteristics of scratch resistance, collision resistance and corrosion resistance-even if the display screen of horizontal inquiry machine is slightly collided by luggage and carts in crowded scenes such as government halls and airports, the fuselage will not be sunken or painted.
Long-term exposure to outdoor semi-open space (such as under the awning of the station square) can also resist material aging caused by rain splashing and dust accumulation.
Structural design and safety adaptation of display screen of horizontal inquiry machine: the machine body adopts "fully enclosed+hidden interface" design, and the interface area (USB, HDMI, power interface) is located on the side of the machine body, equipped with dustproof and waterproof cover plate to reduce dust and liquid infiltration in public scenes.
The customized base and fuselage of the display screen of the horizontal inquiry machine adopt an integrated welding process, and the anti-slip rubber pad is added at the bottom.
When the whole machine is placed on smooth floors such as marble and cement, it can withstand 15 inclination without toppling, so as to avoid equipment displacement caused by collision of children or crowded people. In addition, the steel plate body has good electromagnetic shielding performance, which can reduce the interference of strong electromagnetic environment, such as hospital MRI equipment and airport security inspection instrument, to ensure the stability of data transmission.
C, horizontal query machine display screen public service scene subdivision application and adaptation scheme
(1) government service hall scene
Core application requirements of horizontal inquiry machine: it needs to run stably for 7×24 hours, support business inquiry (such as social security payment record and business license processing process) and self-service declaration (such as tax declaration and social security enrollment registration), and cope with environmental changes such as crowded people in the morning peak, low load at noon and low temperature at night.
Advantages of the display screen adaptation of the inquiry machine: wide temperature characteristics ensure that the equipment will not be turned off at night in winter (-5℃~10℃) and maintain the basic inquiry function; The display screen body of cold-rolled steel plate horizontal inquiry machine can withstand high-frequency touch and collision, and adapt to the daily use intensity of thousands of people; X86 system (optional i3/i5 CPU) can be connected to the government intranet to realize real-time data synchronization, and the social security and tax information inquired by users is consistent with the official system to avoid information lag; The built-in dual coaxial speakers support SRS surround sound, which can clearly convey the government announcement even if the hall is noisy.
(Unfinished)
