Ip6510 point lcd touch screen rugged all in one embedded industrial panel pc monitor machine
industrial contrial screen-10
$400
Feature: liquid crystal display;acer 165hz monitor;pro display;micro led display
Size: 10.1'';13.3'';15.6'';19'';21.5'';27'';32'';18.5'';24'';43'';20cmx20cm;25cmx25cm
Operation System: Android;Windows
Screen: Touchscreen
Installation: Vertical;Horizontal;Wall-mounted;Portable
Type: Advertising Machine;Digital Signage Display;Industrial Control Machine
Product Details
Product Details
Installation Methods and Dimensions of Touch Industrial Control Screen
The installation methods and dimensions of the touch industrial control screen are meticulously designed to cater to diverse industrial environments, combining flexibility with structural stability. This 21.5-inch touch industrial control screen offers multiple mounting solutions that prioritize ease of integration, space optimization, and operational accessibility, ensuring it can be seamlessly incorporated into various industrial setups. The dimensional engineering balances visual clarity with compact form, making it a versatile choice for both new installations and retrofitting existing systems.
The touch industrial control screen features a sleek 21.5-inch display with physical dimensions tailored for industrial applications. The overall outer casing measures 554mm in width, 355mm in height, and 75mm in depth, providing a substantial viewing area while maintaining a manageable footprint. The display area itself spans 478.8mm*271.3mm, offering a 16:9 aspect ratio that optimizes content visibility for industrial interfaces, from production metrics to machine control panels. The touch industrial control screen’s slim profile, achieved through a die-cast aluminum alloy rear cover, not only enhances its aesthetic appeal but also facilitates installation in space-constrained environments.
One of the primary installation methods for the touch industrial control screen is wall-mounted installation, designed for easy accessibility and space-saving. The device comes with a standard 100mm*100mm VESA mounting pattern on the rear panel, compatible with most commercial wall brackets. This mounting solution allows the touch industrial control screen to be positioned at optimal eye level for operators, reducing strain and improving workflow efficiency. The wall-mounted design is ideal for monitoring stations, control rooms, or production lines where centralizing visual interfaces enhances operational oversight. The robust aluminum construction ensures the touch industrial control screen remains stable even when mounted in high-traffic areas or environments with minor vibrations.
The touch industrial control screen also offers desktop stand installation, providing flexibility for temporary setups or mobile workstations. The stand is designed to support the device’s 3.3Kg net weight (3.8Kg gross weight with packaging), featuring an adjustable tilt mechanism that allows users to find the optimal viewing angle. This installation method is suitable for quality control stations, temporary monitoring posts, or environments where the touch industrial control screen needs to be repositioned frequently. The desktop stand is constructed from the same durable aluminum as the main housing, ensuring consistency in build quality and resistance to industrial wear and tear.
Electrical installation considerations for the touch industrial control screen are simplified by its universal power input (AC 100V～240V 50/60Hz) and compact DC 12V 5A power adapter. The device supports power-on self-boot functionality, a critical feature for industrial applications that require unattended operation or quick resumption after power interruptions. The touch industrial control screen’s interface layout, while varying by motherboard configuration, is designed for easy cable management during installation, with ports positioned to minimize clutter and facilitate maintenance.
Customization options for installation further enhance the touch industrial control screen’s adaptability. The device can be modified to include specialized mounting brackets, extended cable lengths, or integrated mounting accessories to suit unique industrial requirements. For example, in food processing plants, the touch industrial control screen can be fitted with stainless steel mounting hardware to meet hygiene standards, while in heavy machinery applications, reinforced brackets can be added to withstand extreme vibrations. These customization capabilities ensure the touch industrial control screen can be tailored to the specific needs of any industry.
During the installation process, the touch industrial control screen’s rugged construction plays a key role in ensuring safety and reliability. The aluminum alloy housing provides a solid foundation for mounting, while the tempered glass front panel resists impacts during handling or installation. The device is designed to be installed by qualified technicians, with clear instructions provided in the user manual to guide the process. Proper installation not only ensures the touch industrial control screen functions optimally but also maintains its protection ratings, such as IP65, by ensuring all seals and gaskets are correctly positioned.
The dimensional accuracy of the touch industrial control screen is crucial for both standard and custom installations. The device undergoes rigorous quality checks to ensure that its dimensions match the specified tolerances, allowing for consistent fitment in pre-designed enclosures or mounting systems. This precision is particularly important for embedded installations, where even minor dimensional variations could affect the seal integrity or overall appearance. The touch industrial control screen’s design prioritizes compatibility with industry-standard mounting solutions, reducing the need for custom tooling and streamlining the integration process.
In summary, the installation methods and dimensions of the touch industrial control screen reflect a deep understanding of industrial integration needs. From wall-mounted to embedded and desktop configurations, the device offers versatile mounting solutions that balance functionality with space efficiency. The precise dimensional engineering and robust construction ensure that the touch industrial control screen can be safely and reliably installed in a wide range of environments, while customization options allow for tailored solutions to meet specific industry demands. This focus on installation flexibility and dimensional precision makes the touch industrial control screen a practical and adaptable choice for industrial applications worldwide.
